- Size: 6000*1970*2735mm
- Place of Origin: Jinan shandong
- Brand Name: CHARGEWE
- Model Number: CW-600GFJ
- Weight: 11500.000 kg
Requirement for biomass gas
Within 1m to the intake valve of gas generator set
1. Generator temperature≤40 ℃
2.Pressure 3-10kpa ,pressure changing rate ≤ 1kpa/min
3.H 2 S ≤ 200mg/Nm 3
4.NH 3 ≤ 20 mg/Nm 3
5.Tar content ≤ 20 mg/Nm 3
6.Impurity particle size ≤ 5um .impurity content ≤ 30 mg/Nm 3
7.Moisture content ≤ 40 g/Nm 3
8.Heat value ≥ 4.2mj/Nm3
Noted : If there are too much sulfur and ammonia in the gas ,it will not only corrode
the electrode of sparking plug heavily but also increase the acid value of engine oil which
will corrode the parts inside of genset ,easy to generate precipitate and increase the attrition
corrosion to the engine.
Genset No. | CW-600GFJ |
Engine No. | 12V190ZLT |
Gas mix type | outside |
Rated power | 600kw |
Continuous power | 500kw |
Rated voltage | 400V/230V |
Phase | 3phase4wire |
Rated frequency | 50Hz |
Rated rotation | 1000r/min |
Rated power factor | 0.8 |
Rated current | 1020A |
Frequency steady state regulation rate | ≤ 0.5 ％ |
Voltage regulating range | 95-105 ％ |
Heat consumption | ≤ 11.5mj/kw.h |
Lubricant consumption | ≤ 1.5g/kw.h |
Gas pressure | 3-20kpa |
Cylinder number | 12v |
Cylinder diameter | 190mm |
Stroke | 210mm |
Compression ratio | 8:1 |
Starting mode | 24V electric motor |
Overhaul time | ≥ 25000h |
Noise | ≤ 105 |
Intake mode | Supercharging,inter- cooled |
Sparking mode | Sparking plug |
Voltage regulation mode | automatic |
Speed regulation mode | Electric speed regulate |
Lubrication mode | Pressure and splash |
Cooling mode | Closed/open cooled |
Exhaust temperature | ≤ 650 ℃ |
Displacement | 71.45L |
Size (mm) | 6000*1970*2735 |
FAQ:
1.How to choose the right model?
A: It depends on real output power, Voltage, Frequency and gas type.
2.What is the oil consumption and capacity per hour?
A: 1.0-1.63g of lubricant oil consumption per hour. 1.0 Cubic meter gas can produce 1.5-3.0kw/h
power. The capacity depends on gas energy. E.g 1.0 Cubic meter natural gas produce about 3.0kw/h
3.What is the overhaul?
A: About 30000 working hours. A week is enough to finish.
4. What is the warranty?
A: 1 year. Inside this 1 year, we offer all spare parts free of charge. After this period, spare
parts are not free. But, a set of spare parts will be shipped together with machine free.
5. How is the service?
A: We offer installation,repair and maintain service abroad. And online guide service if needed
anytime. Our before-sale, in-sale and after-sale service are all trustable, you can name it.
