- Size: 2300×850×1350
- Place of Origin: Jinan, Shandong
- Brand Name: CHARGEWE
- Model Number: CW-40GFT
- Weight: 1200.000 kg
Requirements for Nature gas
Within 1m from pressure regulating valve of gas intake .
1. The ratio of CH4 in nature gas ≥70%
2. Pressure of nature gas :80~200kpa ,rate of pressure change ≤1kpa/min .
3. H2S≤20mg/Nm3
4. Moisture content ≤ 40g/Nm3
5. Impurity particle size ≤5um,impurity content≤30mg/Nm³
Genset No. CW-40GFT Engine No. CW6105 Type outside Rated power 40kw Rated voltage 400V/230V Phase 3P4W Rated Frequency 50Hz Rated speed 1500r/min Rated power factor 0.8 Rated current 72A Heat consumption ≤ 11.5mj/kw.h Pressure 8-200kpa Cylinder No. 6 Cylinder diameter 105mm Stroke 125mm Compression ratio 11:1 Intake mode Natural intake Sparking mode Spark plug Voltage regulation mode automatic Speed regulation mode Electric speed regulate Lubrication mode Pressure and splash Cooling mode Circulating water cooled Start mode 24V electric motor Overhaul time ≥ 25000h Noise ≤ 105 Exhaust temperature ≤ 650 ℃ Displacement 5.2L Size 2300 × 850 × 1350 Weight 1200kg
- Size: 2300×850×1350
- Place of Origin: Jinan, Shandong
- Brand Name: CHARGEWE
- Model Number: CW-40GFT
- Weight: 1200.000 kg
