- Size: 6000×1900×2170
- Place of Origin: Jinan, Shandong
- Brand Name: CHARGEWE
- Model Number: CW-200GFZ
- Weight: 4000.000 kg
Biogas generator sets application
1.Breeding enterprise-biogas generator power
2.Industry- clcohol plant ,starch factory anaerobic sewage treatment
3.refuse landfill-sewage biogas generator power
Requirements for biogas genset
Within 1m from pressure valve of gas intake
1.Gas temperature≤40℃
2.Pressure 3~20Kpa,pressure changing rate≤1kpa
3.H2S≤200mg/Nm3
4.NH3≥20mg/Nm3
5.CH4 content≥40%,changing rate≤30mg/Nm3
6.Impurity particle size ≤5μm
7.Moisture content ≤40g/Nm3
Model No. CW-200GFZ Engine No. CW12V135 Gas mix type outside Rated power 200kw Rated voltage 400V/230V Phase 3p4w Rated frequency 50Hz Rated rotation 1000r/min Rated power factor 0.8 Rated current 360A Heat consumption ≤ 11.5mj/kw.h Gas pressure 3-20kpa Cylinder number 12 Cylinder diameter 135mm Stroke 150mm Compression ratio 10:1 Aspiration mode Naturally aspirated Ignition method plug ignition Pressure regulation mode Automatic pressure regulation Speed regulation mode Electronic speed regulation Lubrication mode Pressure and splash lubrication Cooling mode Closed/open cooling Starting mode 24V electric motor Overhaul period ≥ 25000h Noise ≤ 105 Exhaust temperature ≤ 650 ℃ Displacement 25.4L Genset dimensions 6000 × 1900 × 2170 Genset weight 4000kg
- Size: 6000×1900×2170
- Place of Origin: Jinan, Shandong
- Brand Name: CHARGEWE
- Model Number: CW-200GFZ
- Weight: 4000.000 kg
